Description
The Radiographic Examination Report is a professional, ready-to-use Excel template designed to document radiographic testing (RT) of piping welds and metallic components in Oil & Gas, EPC, fabrication, and industrial construction projects. It provides a clear and structured reporting format to record all radiographic inspection data in full compliance with project specifications and international codes.

Key Benefits

• Standardized and compliant RT inspection report
• Ensures full traceability of radiographic testing activities
• Facilitates Client audits, quality reviews, and project handover
• Covers multiple radiographic techniques (SWSI, DWSI, DWDI)
• Editable, practical, and immediately usable in the field or workshop

File Content

• Project, client, and examination identification
• Weld and component details (line number, joint number, welder ID)
• Radiographic technique used (SWSI, DWSI, DWDI)
• Exposure parameters and source details
• Film type, IQI selection, and placement
• Radiographic density readings and image quality results
• Acceptance and rejection status per applicable code
• Remarks and corrective actions, if any
• Inspector identification, certification, and validation signatures

Use Case
This report is used during radiographic testing activities to formally document RT inspections of welds and components. It is intended for NDE personnel, QA/QC inspectors, EPC contractors, fabrication shops, and construction teams requiring a reliable, compliant, and audit-ready radiography reporting format aligned with ASME Section V and ASME B31.3 requirements.
