Description
The Radiographic Examination Procedure provides a complete, field-ready methodology for performing radiographic testing (RT) on welds and piping components in Oil & Gas, EPC, fabrication, and industrial construction projects. Developed in full alignment with ASME Section V, ASME B31.3, and typical Client specifications, this procedure ensures consistent execution of radiographic inspections and full compliance with international NDE and project quality requirements.

Key Benefits

• Comprehensive and standardized RT methodology
• Fully compliant with ASME codes and Client requirements
• Ensures reliable defect detection and consistent inspection quality
• Defines clear roles, responsibilities, and qualification requirements
• Ready to use, practical, and easily integrated into project QMS

File Content

• Purpose, scope, and applicability of radiographic examination
• Definitions, abbreviations, and reference standards
• Equipment and source requirements
• Radiographic techniques (SWSI, DWSI, DWDI)
• Film type, screens, and IQI selection criteria
• Sensitivity requirements and density control
• Exposure parameters and film processing rules
• Identification and traceability requirements
• Radiation safety rules and controls
• Personnel responsibilities and qualification requirements (ASNT SNT-TC-1A / ISO 9712)
• Annex: Radiographic Examination Report template for piping welds

Use Case
This procedure is intended for NDE personnel, QA/QC teams, fabrication workshops, construction sites, and EPC contractors. It is used during welding inspection and quality control activities to standardize radiographic testing, support Client acceptance, ensure audit readiness, and maintain full regulatory and contractual compliance throughout project execution.
